K03B9

K03B9

1,70 €

FIC068

Σε απόθεμα

Guaranteed Safe Checkout
  • RJK03B9DPA, K03B9
    Features
    •High speed switching
    •Capable of 4.5 V gate drive
    •Low drive current
    •High density mounting
    •Low on-resistance RDS(on) = 8.3 mΩ typ. (at VGS = 10 V)
    •Pb-free
    •Halogen-free

    Absolute Maximum Ratings
    Drain to source voltage 30V
    Gate to source voltage ±20V
    Drain current 30A
    Drain peak current 120A
    Body-drain diode reverse drain current 30A
    Avalanche current 8A
    Avalanche energy 6.4mJ
    Channel dissipation 25W
    Channel to case thermal impedance 5°C/W
    Channel temperature 150°C
    Storage temperature –55 to +150°C
